Thermogravimetric Analysis of Biochar
As a result, TGA is particularly useful for examining new biobased materials and products and in comparing them against the alternatives (biobased and non-biobased) that currently exist in the marketplace.
Thermogravimetric analysis involves the weight of a sample being recorded as the temperature it is exposed to increases. TGA produces a curve, that shows the effect of temperature (or time), presented on the x axis, on the weight of the sample (the y axis). The weight is usually expressed in terms of the percentage of the sample that remains, versus the weight at the start of the experiment, at a given temperature/time.
We can undertake this analysis in a range of different atmospheres, with nitrogen and air being the most commonly used. At Celignis we would normally recommend using nitrogen as the enivronmental gas as this allows you to evalaute the volatility of the sample at different temperatures without the interference of combustion on the results.
Thermogravimetric Analysis of Biochar
TGA can also be used to study the effect of upgrading (e.g. chemical and physical treatments) on the thermal stability of biochars. For example, one study investigated the effect of acid treatment on the thermal stability of biochar produced from sugarcane bagasse. The study found that the acid-treated biochar exhibited a higher thermal stability than the untreated biochar, indicating that the acid treatment improved the thermal stability of the material.
TGA can also be used to study the chemical composition of biochar. As the sample is heated, different components of the biochar will degrade at different temperatures, resulting in different rates and extents of weight loss. By analyzing the weight loss curve, it is possible to determine the composition of the biochar. For example, TGA can be used to measure the amount of volatile matter in the sample, which is an important factor in determining its suitability for use as a fuel. Comparing the TGA curve of the biochar versus the TGA curve of the original pyrolysis feedstock can be particularly important in this regard.
We can employ various different programs for the TGA analysis, according to your particular preference, or we can recommend a suitable program based on our experience with the thermogravimetric analysis of a wide range of materials. Such properties that can be changed include:
- The temperature range over which the experiment is conducted.
- The rate of change of the temperature (for example an increase of 5 degrees Celcius per minute).
- Whether there are periods during which the temperature is held constant for a set period of time.
- Combinations of the above temperature treatments, for example periods during the program where the temperature is maintained coupled with phase(s) where one or more temperature gradients are applied.
- Different environmental gases used at different stages of the program. For example, we can run under a nitrogen atmosphere until the final stage of the program where air is then introduced, allowing the sample to be incinerated with only the ash remaining.
- Whether the data are reported as a function of time or temperature. We normally report results with temperature on the x axis but can change this according to your preference. We can also present the DTG curve in various forms.
Celignis Analysis Packages for Thermogravimetric Analysis of Biochar
Thernogram - Under Nitrogen, Thermogram - Under Air, Moisture, Inherent Moisture, Ash Content (815C), Carbon, Hydrogen, Nitrogen, Sulphur, Oxygen, Organic Carbon, Inorganic Carbon, Chlorine, Volatile Matter, Fixed Carbon, Aluminium, Calcium, Iron, Magnesium, Phosphorus, Potassium, Silicon, Sodium, Titanium, Gross Calorific Value, Net Calorific Value, Ash Shrinkage Starting Temperature (Reducing), Ash Deformation Temperature (Reducing), Ash Hemisphere Temperature (Reducing), Ash Flow Temperature (Reducing)
Thernogram - Under Nitrogen, Thermogram - Under Air, Moisture, Inherent Moisture, Ash Content (815C), Carbon, Hydrogen, Nitrogen, Sulphur, Oxygen, Organic Carbon, Inorganic Carbon, Chlorine, Volatile Matter, Fixed Carbon, Specific Surface Area (Nitrogen Gas Adsorption), Calcium, Iron, Magnesium, Phosphorus, Potassium, Silicon, Sodium, Titanium, Gross Calorific Value, Net Calorific Value, Ash Shrinkage Starting Temperature (Reducing), Ash Deformation Temperature (Reducing), Ash Hemisphere Temperature (Reducing), Ash Flow Temperature (Reducing)
